Description
Whether you have a mixing application that involves only a few channels, or up to 32 inputs with substantial signal routing versatility, Yamaha’s MG series offers a mixing console that will give you the capacity, control, and performance you deserve. All models are remarkably compact and lightweight for superior handling and portability, but absolutely no compromises have been made in terms of features, performance, or durability. The MG mixers offer an extraordinary blend of technology: some inherited from professional Yamaha mixing consoles you’re likely to see in distinguished halls throughout the world, and some developed specifically to deliver optimum performance in the MG-console format. In either case these performance-packed Yamaha mixers are founded on a world-spanning network of human and technological resources that crystallize to deliver features that really matter, and sound that is undeniably superior.
FEATURES
Built-in SPX Digital Effects
Easy operation
Lightweight, portable design
Versatile connectivity and pro-class connectors
Built-in channel compressors
High-performance microphone preamplifiers with switchable phantom power
3-band Channel EQ and high-pass filters
Aux/Effect sends
Smooth 60mm faders and illuminated channel ON switch
Bright meters for visual level monitoring
SPECIFICATIONS
Mic/Line inputs: 10
Line inputs: 8 mono + 4 stereo
Mixer input channels: 16
Group busses: 4
AUX busses: 3
including 1x Effect send
Main busses: Stereo
Total harmonic distortion (THD+N): Less than 0.1%, 20Hz-20kHz
Frequency response: 0, +1, -3dB, 20Hz-20kHz
Equivalent input noise (EIN): -128dBu
Residual output noise: -98dBu
Crosstalk (1kHz): -70dB
Power supply adaptor: PA-30 AC adaptor (AC35VCT, 1.4A); 100V, 120V, 220V, 230V or 240V, 50/60Hz
Power consumption: 35W
Dimensions: 478x105x496 mm
Net weight: 5.5 kg
Accessories: Owners manual, AC adaptor
