Description
From the carefully selected transducers to the proprietary enhanced waveguides and to the low-resonance cabinet design, everything has been tailored with hours of listening in order to offer the best accuracy over the whole audio spectrum.
The perfectly optimized electronics, including high-headroom separate Class AB amplifiers for high and low section, high-precision crossover networks and separate LIMITER circuits, provide maximum resolution and minimum listening fatigue.
The lineup includes three models, featuring 5.25”, 6” and 8” woofers, and a 10” subwoofer, offering the ideal nearfield monitor solution for any kind of music production applications: recording studios, home and project studios, broadcast studios, post-production facilities, mobile production vehicles, home theater, multimedia installations.
- Bi-amplified 2-way system
- 1 “soft-dome tweeter for detailed response and a high-resolution sound
- Proprietary integrated elliptical waveguide with accurate directivity control
- Long-excursion 8” woofer with lightweight fiber-glass composite cone
- Precisely calculated front tuning port for greater low-frequency extension
- Multiple audio input connectors for connecting any kind of source
- HF adjustment for a flexible control of high frequency response
- Sophisticated, carefully designed crossover filters for an improved resolution
- High-headroom Class AB 20+70W amplifiers with dual accurate CLIP LIMITER
- SPL MAX 109 dB
- Frequency response 45 Hz – 20 kHz
-
System type 2-way vented enclosure High Frequency Device 1 “ dome tweeter on elliptical waveguide Low Frequency Device 8” woofer with fiberglass reinforced cone Angular Coverage 90° H x 60° V HF Amplifier Continuous Power 20W Class AB LF Amplifier Continuous Power 70W Class AB Processing Analog Frequency Response 45 Hz – 20 kHz Max SPL 109 dB Connectors 1/4” JACK, XLR-F, RCA Controls LEVEL, HF ADJUST Construction Vinyl laminated MDF cabinet with ABS front Cabinet Colour Black Power Supply 230 VAC or 120 VAC 50/60 Hz with LINE VOLTAGE selector Dimensions (W x H x D) 265 x 380 x 305 mm Weight 10 kg
