Description

• 20 state-of-the-art low-noise Mic Preamps
• Mono channels with 4-band EQs with 2 sweep mid, Lo-Cut, Insert and Direct Out
• 4 stereo Line inputs with 4-band EQs
• 6 Aux sends per channel pre/post fader switchable
• Peak and Signal LEDs plus Mute, Solo, Subgroup and Main routing switches on all channels
• Aux 1 to 4 with 3-band EQ, 60mm faders and Insert for advanced stage monitoring
• 4 Subgroup outputs with Inserts
• 2 independent Main outputs with Inserts on Main Mix
• 2 Stereo Returns with comprehensive routing options
• 2 Headphones and 1 Monitor outputs with independent level control
• Solo-In-Place with PFL/AFL function plus full-featured Talkback section
• Main Mute function
• 2 independent 24-bit PROFEX digital effects with 256 studio-grade presets including reverbs, delays, chorus and combination effects
• USB audio IN/OUT interface with comprehensive routing options
• Long-wearing 100 mm logarithmic-taper faders
• High-resolution 2 x 16-LED bar meters
• Balanced Main Mix, Main B and AUX 1-4 outputs with XLR connectors
• USB connectors for the use of 5V lamps
• Internal universal power supply (100 – 240 V~)
• High-quality components and rugged construction for the maximum durability
• Designed and Engineered by PROEL Italy
