Description
Key Features
|
|
Full range impact
The IMPACT 215LL has the highest power in any of our dual 15″ modelsWith 3200w peak, IMPACT 215LL is HUGE!For high frequency, a 1.75″ titanium diaphragm compression driver produces a powerful yet neutral sounding high end. Both the HF and 2 x 15” LF drivers have been newly developed for this loudspeaker series, engineered and acoustically matched to an extremely durable MDF cabinet.
Built to take an impact
As with all of the IMPACT series, IMPACT 215LL is ready for whatever life on tour throws at it.The strong MDF cabinet is covered in a textured black paint to give a durable yet stylish finish, which brings a professional look to any sound reinforcement environment.The finish is extremely hard wearing and is leagues above any other carpet covered cabinet in the same price point.
90° x 60° Elliptical waveguides
For wide and smooth coverage a 90° x 60° elliptical waveguide has been selected.In real-world terms this means that the higher frequencies can be heard with definition at 90° in the horizontal plane, and 60° in the vertical.All models in the Impact series use this same elliptical waveguide design which makes for controllable coverage when using multiple Impact series loudspeakers.
Huge power handling
The most powerful dual 15″ Impact model in the series.Custom designed Wharfedale Pro drivers are combined with a detailed crossover network. This combination leads to an extremely powerful system – but with a full-range sound.Simply put…IMPACT 215LL goes LOUD!
SPECIFICATIONS
| Model Name | IMPACT 215LL |
| System type | Passive |
| Configuration | 2 x 15″ 2-way |
| Frequency Response (+/-3dB) | 45Hz – 18kHz |
| Frequency Range (-10dB) | 40Hz – 20kHz |
| Sensitivity (2.83v/1m) | 101dB |
| System Rated Impedance | 4Ω |
| Calculated Maximum SPL@1m | >135dB |
| Low Frequency Transducer | |
| Size | 2 x 381mm / 15″ |
| Voice coil size | 65mm / 2.5″ |
| Rated Impedance | 8Ω |
| LF Power (re:AES-2012) | 2 x 400w |
| HF Transducer | |
| HF Driver type | Compression driver |
| Voice coil size | 44mm / 1.75″ |
| Exit size | 25mm / 1″ |
| Diaphragm Material | Titanium |
| Rated Impedance | 8Ω |
| HF Power (re:AES2-2012) | 40w |
| Nominal Coverage (HxV) | 90° x 60° |
| Nominal Impedance | 8Ω |
| Power | |
| System Continuous Power | 800w |
| System Programme Power | 1400w |
| System Peak Power | 3200w |
| Crossover frequency | 2.2kHz |
| Hardware | 2 x combi-jack inputs |
| 2 x carry handles | |
| Enclosure | |
| Enclosure Material and finish | MDF |
| Colour options | Black rhino rock paint |
| Grille Material & Finish | Black steel |
| Dimensions – Unpacked | |
| Height | 1300mm / 51.18” |
| Width front | 520mm / 20.47” |
| Width rear | 300mm / 11.81” |
| Depth | 500mm /19.68” |
| Dimensions – Packed | |
| Height | 1367mm / 53.82” |
| Width front | 594mm / 23.39” |
| Width rear | 344mm / 13.54” |
| Depth | 567mm / 22.32” |
| Net weight | 45.0kg / 99.2lbs |
| Gross weight | 56.0kg / 123.5lbs |
