Description
Key Features
|
|
![](https://www.wharfedalepro.com/upload/images/product_other/20180621115648_4305.gif)
![](https://www.wharfedalepro.com/upload/images/product_other/20180705095958_4411.png)
![](https://www.wharfedalepro.com/upload/images/product_other/20180705133738_4465.jpg)
![](https://www.wharfedalepro.com/upload/images/product_other/20180710164651_4566.jpg)
SPECIFICATIONS
Model Name | DELTA-X15M |
System Type | Passive |
Configuration | Two-way |
Frequency Response (+/-3dB) | 55-20kHz |
Frequency Range (-10 dB) | 50-20kHz |
Sensitivity (2.83v/1m) | 98dB |
Calculated Maximum SPL @1m | 131dB |
System Rated Impedance | 8Ω |
Low Frequency Transducer | |
Size | 404mm / 15″ Paper |
Voice Coil Size | 77.1mm / 3″ |
Rated Impedance | 8Ω |
LF Power (re:AES2-2012) | 500W |
High Frequency Transducer | |
HF Driver Type | Compression Driver |
Voice Coil Size | 50.8mm / 2″ Titanium |
Exit Size | 35.6mm / 1.4″ |
Diaphragm Material | Titanium |
Rated Impedance | 8Ω |
HF Power (re:AES2-2012) | 50W |
Nominal Coverage (H x V) | 90⁰ x 45⁰ |
Power | |
System Continuous Power | 500W |
System Programme Power | 1000W |
System Peak Power | 2000W |
Crossover frequency | 1.8kHz |
Input Connector | 2 x NL4 (speakON Compatible) |
Hardware | |
Handles | 2 on Sides |
Enclosure | |
Enclosure Material | 15mm Plywood |
Finish | black paint |
Grille Material & Finish | 1.5 mm Steel Black |
Dimensions – Unpacked | |
Height | 493(SITU)mm / 19.4″ |
Width Front | 446mm / 17.6″ |
Width Rear | 446mm / 17.6″ |
Depth | 685mm / 27.0″ |
Dimensions – Packed | |
Height | 518mm / 20.4″ |
Width Front | 757mm / 29.8″ |
Width Rear | 757mm / 29.8″ |
Depth | 565mm / 22.2″ |
Weight | |
Net Weight (kg / lbs) | 27.24kg / 59.9lbs |
Gross Weight (kg / lbs) | 33.96kg / 74.7lbs |
