Description
FEATURES
●High quality plywood with special environmental protection paint
●Very high SPL from a full range passive enclosure
●Fiberglass 90o×50o horn
●Dedicated low distortion mid-bass driver
●Used for moving performance, multi-purpose hall and high-end hotel
SPECIFICATIONS
FREQUENCY RESPONSE(-3dB) | 45 Hz-18kHz |
FREQUENCY RESPONSE(-10dB) | 40 Hz-20kHz |
DRIVERS | 2×15″(385mm)/4″voice coil LF |
1×2″(50mm)/3″voice coil HF | |
RATED POWER | 1200W RMS,4800W peak |
SENSITIVITY | 101dB 1watt/1 metre |
MAXIMUM SPL | 131dB continuous,137 dB peak |
IMPEDANCE | 4 ohms nominal |
DISPERSION(-6dB) | 90°×50° |
CROSSOVER FREQUENCIES | 1.5 kHz passive |
INPUT CONNECTORS | 2×Speakon NL4 |
PACKAGE SIZE | 660mm×605mm×1250mm |
NET WEIGHT | 50 kg/pc |
GROSS WEIGHT | 56 kg/pc |
CONFIGURATION
