Description

FEATURES

●High quality plywood with polyurea waterproof paint
●High quality neodymium components
●Patent line array horn
●Small cabinet with light weight, but with high SPL
●Passive or Bi-amp operation
●Convenient for hanging and stacking
●Good used for moving performance,small scale theater and band

SPECIFICATIONS



MODEL MLA110
FREQUENCY RESPONSE(-3dB) 55Hz-18KHz
FREQUENCY RESPONSE(-10dB) 50Hz-20KHz
DRIVERS 1×10″(250mm)/3″voice coil LF
1×1.4″(36mm)/3″voice coil HF
RATED POWER 250W RMS,1000W peak
SENSITIVITY 98dB  1watt/1meter
MAXIMUM SPL 122dB continuous,128dB peak
IMPEDANCE 16 ohms nominal
DISPERSION(-6dB) Horizontal coverage100°Vertical coverageVaries, depending on array length and configuration
CROSSOVER FREQUENCIES 1.3kHz passive
INPUT CONNECTORS 2×Speakon NL4
PACKAGE SIZE 525mm×410mm×640mm
NET WEIGHT 20 kg/pc
GROSS WEIGHT 23 kg/pc



CONFIGURATION

DOWNLOAD
